Vero White Plus 3D Printing Material

Material Name:

Vero White Plus RGD835

Description:

VeroWhitePlus is a rigid, opaque white material used in PolyJet 3D printing processes. It offers high dimensional stability, fine detail resolution, and excellent surface finish. The material is ideal for producing prototypes, concept models, and parts that require a high-quality, smooth finish and precise details. Its white color provides a neutral base for painting or finishing.

Material Type:

Rigid Photopolymer Resin

Price:

Available color:

White

Process compatibility:

PolyJet compatible

Special Properties:

High Detail Resolution
Excellent Surface Finish
Rigid and Durable
Multiple Colors Available in Vero Family
High Fatigue Strength
Multi-Material Printing Capabilities

Limitations:

Brittle Compared to Engineering Plastics
Limited Thermal Resistance
UV Sensitivity
Requires Support Removal and Post-Processing

Key Vero White properties rated to guide you in selecting the best fit for your 3D printing needs.

Strength3 of 5

Flexibility1 of 5

Detail Resolution5 of 5

Surface Smoothness5 of 5

Heat Resistance2 of 5

Chemical Resistance2 of 5

Ease of Printing5 of 5

Cost Efficiency3 of 5

VeroWhitePlus is ideal for producing prototypes, concept models, and parts that require fine details and a smooth surface finish. It is suitable for visual models, fit and form testing, and models requiring a high-quality appearance.

Product Design and Development Applications

Concept models
Aesthetic prototypes
Fit and form testing

Consumer Products Applications

Electronics casings
Household items
Toys and figurines

Medical and Dental Applications

Anatomical models
Dental study models
Surgical planning models

Architecture and Art Applications

Architectural models
Sculptures
Exhibition displays

Additional Applications

High-Resolution Models
Multi-Material Assemblies
Parts Requiring Painting or Finishing

Provides rigidity and dimensional stability, suitable for prototypes and models requiring fine details and smooth surfaces.

Property	Value, metric
Tensile Strength	Approximately 50-65MPa
Tensile Modulus	Approximately 2,000-3,000 MPa
Elongation at Break (%)	10-20%
Flexural Strength	Approximately 75-110 MPa
Flexural Modulus	Approximately 2,200-3,200 MPa
Notched Izod Impact Strength	Approximately 20-30 J/m
Shore Hardness	Shore D 83

Characteristics

Printing with VeroWhitePlus involves PolyJet technology, which jets layers of photopolymer resin and cures them with UV light. The process allows for high-resolution printing with smooth surfaces and fine details. Support material is used for overhangs and is removed during post-processing.

Type	Value
Lead Time	1-3 business days
Wall Thickness	Minimum 0.6 mm
Tolerance	±0.1%, minimum ±0.1 mm
Max Part Size	Up to 490 x 390 x 200 mm
Layer Height	-

Thermal Properties

Limited thermal resistance; suitable for applications at room temperature.

Property	Value, metric
Heat Deflection Temperature (HDT)	Approximately 45-50 °C at 0.45 MPa
Thermal Expansion Coefficient	-
Thermal Conductivity	-
Max Service Temperature	Up to 45°C for continuous use

Electrical Properties

Acts as an electrical insulator, suitable for non-conductive applications.

Property	Value, metric
Dielectric Strength	Approximately 15-25 kV/mm
Dielectric Constant (1 MHz)	Approximately 2.8-3.2
Volume Resistivity	Approximately 10^13 Ω·cm
ESD Safety	Not ESD safe

NOTE: The provided values are approximate and can vary based on the specific Vero White Plus formulation and manufacturer. Always refer to the manufacturer's technical data sheet for precise information.

Find your queries

Frequently Asked Question(FAQ)

What is VeroWhitePlus, and what are its primary uses?: VeroWhitePlus is a rigid, opaque white photopolymer material used in PolyJet 3D printing. It is known for its high dimensional stability, fine detail resolution, and excellent surface finish. This makes it ideal for creating prototypes, concept models, and parts that require a high-quality, smooth appearance. The neutral white color provides a great base for painting or finishing, making it suitable for a wide range of applications in product design, consumer goods, and medical models.

How does VeroWhitePlus compare to other PolyJet materials?: VeroWhitePlus stands out among PolyJet materials for its exceptional detail resolution and surface smoothness. While it is more rigid and durable than flexible or elastomeric materials, it does have some limitations, such as being brittle compared to engineering-grade plastics. VeroWhitePlus is perfect for projects that require fine features and aesthetics but is less suitable for parts that need to endure significant mechanical stress or high temperatures.

Is VeroWhitePlus suitable for functional prototypes?: VeroWhitePlus is excellent for creating visual and functional prototypes that require high precision and aesthetic quality. However, it is not ideal for heavy-duty or mechanically demanding applications because it lacks the toughness and impact resistance of engineering plastics. It is best used for models that need to demonstrate form, fit, and function in a controlled environment, such as product mock-ups or architectural models.

Can VeroWhitePlus parts be used for outdoor applications?: VeroWhitePlus is not suitable for long-term outdoor use due to its sensitivity to UV light and limited thermal resistance. Prolonged exposure to sunlight and harsh weather conditions can cause the material to degrade, yellow, or become brittle. If you need a material for outdoor applications, consider using UV-resistant or weatherproof options specifically designed for outdoor durability.

What makes VeroWhitePlus an excellent choice for concept models and visual prototypes?: VeroWhitePlus offers a smooth, high-quality surface finish and crisp detail resolution, making it ideal for concept models and visual prototypes. The material’s white color provides a neutral base for painting or additional surface treatments, and its rigid nature ensures that the printed parts maintain their shape and dimensional accuracy. This combination of features allows designers and engineers to create realistic and visually appealing models.

What are the mechanical properties of VeroWhitePlus?: VeroWhitePlus has a tensile strength of approximately 50-65 MPa and a tensile modulus of 2,000-3,000 MPa, making it a rigid material. It has a flexural strength of 75-110 MPa and a Shore hardness of Shore D 83. The material is durable enough for prototypes and models but is relatively brittle compared to more flexible engineering-grade plastics. It is not suitable for parts that require significant impact resistance or flexibility.

How well does VeroWhitePlus handle mechanical stress?: VeroWhitePlus is designed for rigidity and dimensional stability, which makes it excellent for static models and prototypes. However, it does not perform well under high mechanical stress or repeated flexing, as it tends to be brittle. If your project requires impact resistance or the ability to withstand bending or twisting forces, you may want to explore more flexible or tough PolyJet materials.

What is the heat resistance of VeroWhitePlus?: VeroWhitePlus has limited thermal resistance, with a heat deflection temperature (HDT) of approximately 45-50°C at 0.45 MPa and a maximum service temperature of around 45°C for continuous use. It is suitable for room temperature applications but should not be used in environments where it will be exposed to high heat or thermal cycling, as this could compromise the material's structural integrity.

Is VeroWhitePlus UV resistant?: No, VeroWhitePlus is sensitive to UV light and will degrade over time if exposed to direct sunlight. UV exposure can lead to discoloration, loss of mechanical properties, and increased brittleness. If your application requires UV stability, consider using a material specifically designed for outdoor and UV-resistant applications.

Can VeroWhitePlus parts be used in chemically harsh environments?: VeroWhitePlus has limited chemical resistance and is not recommended for use in environments where it will be exposed to harsh chemicals, solvents, or oils. Prolonged exposure to certain chemicals can weaken or degrade the material. If chemical resistance is a critical requirement for your project, consider alternative materials that are engineered to withstand chemical exposure.

What is the process for 3D printing with VeroWhitePlus using PolyJet technology?: VeroWhitePlus is printed using PolyJet technology, which involves jetting layers of photopolymer resin and curing them with UV light. This process allows for the creation of high-resolution prints with smooth surfaces and fine details. Support material is used for overhangs and complex geometries, and it is removed during post-processing, which typically involves washing, sanding, or polishing the part to achieve the desired finish.

How do I remove support material from VeroWhitePlus prints?: Support material used during the PolyJet printing process can be removed using water jets, manual scraping, or soaking in a solution that dissolves the support structures. Care should be taken to avoid damaging the part’s surface or fine features. After support removal, additional post-processing steps like sanding or polishing may be necessary to achieve a smooth finish.

Can VeroWhitePlus parts be painted or finished?: Yes, VeroWhitePlus parts can be easily painted or finished. The smooth and neutral white surface serves as an excellent base for various finishing techniques, including painting, coating, and polishing. Applying a primer before painting can improve adhesion and result in a more even finish. You can also sand the part to remove any surface imperfections and achieve a polished appearance.

What are some tips for achieving a high-quality surface finish with VeroWhitePlus?: To achieve a high-quality surface finish, consider sanding the part with fine-grit sandpaper, applying a primer, and using multiple coats of paint for a professional look. Polishing compounds can also be used to bring out a glossy finish. If your model has intricate details, be careful not to sand too aggressively, as this can damage the fine features.

Is post-curing necessary for VeroWhitePlus parts?: Post-curing is not typically required for VeroWhitePlus parts, as they are fully cured during the PolyJet printing process using UV light. However, additional UV curing can be performed if extra strength or stability is needed. Always follow the manufacturer's guidelines to ensure the best results for your project.

What types of projects are best suited for VeroWhitePlus?: VeroWhitePlus is ideal for projects that require high detail resolution, smooth surfaces, and rigid structures. Common applications include concept models, visual prototypes, fit and form testing, and models for product design and development. It is also popular in medical and dental fields for creating anatomical models, as well as in architecture for building scale models.

Can VeroWhitePlus be used for creating multi-material parts?: Yes, one of the advantages of PolyJet technology is the ability to create multi-material parts. VeroWhitePlus can be combined with other materials, such as flexible or translucent resins, to create parts with varied mechanical properties and textures. This is particularly useful for prototyping products with soft-touch grips, overmolds, or components with multiple features.

Is VeroWhitePlus suitable for painting and custom finishing?: Absolutely. VeroWhitePlus’s smooth, white surface makes it an excellent candidate for painting and custom finishing. The material takes paint well, and with the right preparation, you can achieve vibrant, high-quality finishes. Artists and designers often use VeroWhitePlus for models that require a realistic appearance or for creating custom sculptures and art pieces.

What are some examples of VeroWhitePlus in product design and consumer goods?: In product design, VeroWhitePlus is commonly used to create concept models of consumer electronics, such as smartphones, headphones, and remote controls. It is also used to prototype household items, toys, and figurines, where fine details and a polished appearance are essential. The material’s rigidity and aesthetic quality make it a favorite for showcasing product concepts to clients and stakeholders.

How does VeroWhitePlus perform in medical and dental applications?: VeroWhitePlus is frequently used in medical and dental applications to create accurate anatomical models, dental study models, and surgical planning aids. The high detail resolution and smooth surface make it suitable for visualizing complex structures, while its rigidity ensures that the models maintain their shape. It is important to note that VeroWhitePlus is not biocompatible, so it should not be used for implants or any applications involving direct contact with the human body.

Can VeroWhitePlus be used for functional parts in assemblies?: While VeroWhitePlus is excellent for visual models and prototypes, it has limitations when it comes to functional parts that experience mechanical stress. The material’s brittleness makes it less suitable for assemblies that require flexibility or impact resistance. However, it can be used for non-load-bearing components or parts that are primarily for display or testing fit and form.

How do environmental conditions affect VeroWhitePlus parts?: VeroWhitePlus parts should be kept in stable, room-temperature environments. Exposure to high heat, UV light, or humidity can negatively impact the material’s properties. For example, UV exposure can cause yellowing and brittleness, while high temperatures may deform or warp the part. Proper storage and handling are crucial to maintain the quality of your printed parts.

Are there any health or safety concerns when working with VeroWhitePlus?: Like all photopolymer resins, VeroWhitePlus should be handled with care. Uncured resin can be irritating to the skin and eyes, so it is important to use protective gear, such as gloves and safety goggles, when handling it. Once cured, the material is safe to handle, but it should still be kept away from food and direct skin contact for prolonged periods. Always follow safety guidelines provided by the manufacturer.

Can VeroWhitePlus be recycled or reused?: Unfortunately, VeroWhitePlus is not recyclable in the traditional sense, and waste material should be disposed of in accordance with local regulations for photopolymer resins. Some recycling programs may accept used support material and failed prints, but these are not common. To minimize waste, try to optimize your prints and use only the amount of material necessary for your project.

How does VeroWhitePlus compare in cost to other PolyJet materials?: VeroWhitePlus is a higher-priced material compared to some standard PolyJet options, but it offers superior detail resolution and surface quality. The cost is justified by its ability to produce high-fidelity models and prototypes that look and feel like finished products. For projects that require less detail or are budget-sensitive, consider using more cost-effective materials. However, for premium models, VeroWhitePlus is often worth the investment.
