Material Name:

Nylon-Like Resin

Description:

Nylon-Like Resin is a high-performance photopolymer resin formulated to mimic the mechanical properties of Nylon, including high tensile strength, flexibility, and impact resistance. It is ideal for producing functional prototypes, mechanical components, and end-use parts that require durability and resilience. The resin offers good dimensional accuracy and surface finish, making it suitable for engineering applications where traditional resins fall short in mechanical performance.

Material Type:

Durable Photopolymer Resin

Price:

Available color:

Gray

Black

Natural

Process compatibility:

SLA compatible

DLP compatible

Special Properties:

High Tensile Strength
Flexibility and Toughness
Good Impact Resistance
Smooth Surface Finish

Limitations:

UV Sensitivity
Requires Post-Curing
Moderate Heat Resistance
Potential for Warping in Large Parts

Key Nylon Like Resin properties rated to guide you in selecting the best fit for your 3D printing needs.

Strength4 of 5

Flexibility4 of 5

Detail Resolution4 of 5

Surface Smoothness5 of 5

Heat Resistance3 of 5

Chemical Resistance3 of 5

Ease of Printing3 of 5

Cost Efficiency3 of 5

Nylon-Like Resin is ideal for producing functional parts that require a combination of strength and flexibility. It is suitable for applications where traditional SLA resins are too brittle, enabling the production of durable components for testing and end-use.

Engineering and Manufacturing Applications

Functional prototypes

Snap-fit assemblies
Mechanical components

Automotive Applications

Brackets and mounts

Interior components
Custom fixtures

Consumer Products Applications

Wearable device components

Flexible enclosures
Sporting goods prototypes

Robotics and Automation Applications

Gears and hinges

Robot components
Flexible joints

Additional Applications

Durable Prototypes

End-Use Parts
Mechanical Testing Models

Provides high tensile strength and flexibility, closely resembling the properties of Nylon.

Property	Value, metric
Tensile Strength	Approximately 60 MPa
Tensile Modulus	Approximately 1,800 MPa
Elongation at Break (%)	15%
Flexural Strength	Approximately 80 MPa
Flexural Modulus	Approximately 2,000 MPa
Notched Izod Impact Strength	Approximately 50 J/m
Shore Hardness	Shore D 80

Characteristics

Printing with Nylon-Like Resin may require adjusted exposure settings due to its unique properties. Post-processing includes thorough cleaning and extended UV curing to achieve maximum mechanical strength and flexibility.

Type	Value
Lead Time	2-5 business days
Wall Thickness	Minimum 0.8 mm
Tolerance	±0.1%, minimum ±0.05 mm
Max Part Size	Up to 600x 600 x 450 mm
Layer Height	-

Thermal Properties

Moderate heat resistance; suitable for parts exposed to slightly elevated temperatures.

Property	Value, metric
Heat Deflection Temperature (HDT)	Approximately 55°C at 0.455 MPa
Thermal Expansion Coefficient	Approximately 70 x 10^-6 /°C
Thermal Expansion (Scale 0-100)	65
Max Service Temperature	Up to 50°C before significant deformation may occur

Electrical Properties

Acts as an electrical insulator; suitable for non-conductive applications.

Property	Value, metric
ESD Safety	Not ESD safe
Conductivity	Non-conductive; insulating properties

NOTE: The provided values are approximate and can vary based on the specific Nylon-Like Resin formulation and manufacturer. Always refer to the manufacturer's technical data sheet for precise information.

Find your queries

Frequently Asked Question(FAQ)

What is Nylon-Like Resin, and how does it differ from standard resins?: Nylon-Like Resin is engineered to mimic the mechanical properties of Nylon, offering higher tensile strength and flexibility compared to standard resins, which are typically more brittle.

Is Nylon-Like Resin suitable for functional parts and mechanical assemblies?: Yes, it is ideal for producing functional prototypes and mechanical components that require durability and flexibility, making it suitable for testing and end-use applications.

How does Nylon-Like Resin compare to actual Nylon used in FDM printing?: While it offers similar mechanical properties, Nylon-Like Resin provides the fine detail and surface finish benefits of SLA printing, which may not be achievable with FDM-printed Nylon.

Does Nylon-Like Resin require special storage conditions?: It should be stored in a cool, dark place away from direct sunlight and UV light sources. Keep the container sealed tightly to prevent contamination and degradation.

What colors are available for Nylon-Like Resin?: Common colors include gray, black, and natural (off-white), which are suitable for functional parts and can be painted if desired.

Are there any special printer settings required for Nylon-Like Resin?: You may need to adjust exposure times and printing speeds based on the resin's properties. Consult the manufacturer's guidelines for optimal settings.

Do I need to use specific supports when printing with Nylon-Like Resin?: Using robust support structures is recommended due to the resin's flexibility, which can affect the stability of overhangs during printing.

How does the resin's viscosity affect the printing process?: Nylon-Like Resin may have a higher viscosity than standard resins, which could affect layer adhesion and print speed. Ensure your printer can handle the resin's viscosity.

Can I print thin-walled parts with Nylon-Like Resin?: Yes, but maintain a minimum wall thickness of 0.8 mm to ensure structural integrity, especially for parts subjected to mechanical stress.

Is an open or closed resin system better for printing with Nylon-Like Resin?: Both systems can work, but a closed system may help maintain resin quality by reducing exposure to light and contaminants.

How long should I UV cure Nylon-Like Resin prints?: Extended curing times, typically 30-60 minutes, may be required to achieve full mechanical properties. Use a UV curing station for best results.

Can Nylon-Like Resin prints be machined or drilled?: Yes, the prints can be machined, drilled, or tapped, but use appropriate tools and proceed cautiously to avoid cracking or damaging the part.

Is it possible to dye or color Nylon-Like Resin prints?: Yes, you can paint the prints using paints suitable for plastics. Priming the surface first can enhance paint adhesion and finish.

How do I remove support structures without damaging flexible parts?: Use flush cutters and remove supports carefully. Soaking the part in warm water can soften the supports, making them easier to remove.

Can I anneal Nylon-Like Resin prints to improve properties?: Annealing is not commonly practiced with resins due to potential deformation. The resin's properties are primarily set during curing.

Why are my prints warping or distorting during printing?: Warping can result from internal stresses or improper support. Ensure adequate support structures and consider adjusting printing orientation.

What causes layer separation in Nylon-Like Resin prints?: Layer separation can be due to insufficient curing between layers or incorrect exposure settings. Verify that your exposure times are appropriate.

How do I prevent print failures with large or complex parts?: Break the model into smaller sections if possible, optimize support structures, and ensure your printer is calibrated and maintained.

Why are my prints exhibiting surface imperfections or roughness?: Surface defects can stem from resin contamination, incorrect exposure settings, or environmental factors. Keep the resin and vat clean, and adjust settings as needed.

How do I fix issues with prints being too flexible or lacking stiffness?: Ensure proper curing times, as under-cured parts may not achieve full mechanical properties. Verify that your printer settings are optimized for the resin.

Can Nylon-Like Resin be used in applications requiring food contact or medical use?: Unless specifically certified, it is not recommended for food contact or medical applications. Always check the manufacturer's certifications.

How does humidity affect printing with Nylon-Like Resin?: High humidity can interfere with resin curing and affect print quality. Print in a controlled environment with low humidity.

Is Nylon-Like Resin suitable for creating living hinges or flexible joints?: Yes, its flexibility makes it suitable for designs incorporating living hinges or flexible elements, but testing is recommended to ensure durability.

Can I mix Nylon-Like Resin with other resins to adjust properties?: Mixing resins is generally not advised as it can lead to unpredictable results. Use resins specifically formulated for your desired properties.

How do I dispose of unused Nylon-Like Resin and cleaning solvents?: Treat uncured resin and contaminated solvents as hazardous waste and dispose of them according to local regulations.
