What is elastic resin 3D printing and when should I use flexible resin?

Elastic resin 3D printing uses flexible resin materials like Elastic Resin 60A to produce soft, rubber-like parts with a Shore hardness of 60A. Use this flexible resin when you need parts that can bend, stretch, and compress—such as wearables, gaskets, and seals.

How does Elastic Resin 60A compare to Flexible Resin 80A?

Elastic Resin 60A is softer and more flexible than Flexible Resin 80A, making it suitable for applications requiring greater elasticity and lower hardness.

Is Elastic Resin 60A suitable for functional prototypes?

Yes, it is ideal for functional prototypes that need to demonstrate flexibility and elasticity, such as wearable devices, seals, and soft-touch components.

Can Elastic Resin 60A be used for end-use parts?

While primarily used for prototyping, it can be used for end-use parts in low-stress applications. Evaluate based on specific requirements and environmental conditions.

Does Elastic Resin 60A require special storage conditions?

Store it in a cool, dark place away from direct sunlight and UV light sources. Keep the container sealed tightly to maintain resin quality.

Are there any special considerations when printing with Elastic Resin 60A?

Yes, due to its softness, it may require adjusted support structures and careful handling to prevent deformation during printing and post-processing.

What layer height is recommended for printing with Elastic Resin 60A?

Layer heights between 50-100 microns are recommended. Smaller layer heights can improve surface finish but may increase print time.

How does Elastic Resin 60A's viscosity affect the printing process?

It may have higher viscosity, which can affect layer adhesion and peel forces. Ensure your printer can handle the resin's properties.

Do I need to adjust exposure settings for Elastic Resin 60A?

Yes, consult the manufacturer's guidelines for optimal exposure settings, as they may differ from standard resins.

How should I handle Elastic Resin 60A prints during post-processing?

Handle prints gently to avoid stretching or deforming them. Use supports to maintain shape during cleaning and curing.

How long should I UV cure Elastic Resin 60A prints?

Extended curing times, typically 20-60 minutes, are necessary to achieve full mechanical properties. Use a curing station with appropriate wavelength and intensity.

Can Elastic Resin 60A prints be dyed or colored?

Yes, prints can be colored using fabric dyes suitable for elastomeric materials. Always test on a small area first.

How do I remove support structures without damaging the print?

Carefully cut supports with sharp tools and avoid pulling or twisting. Supports can be softened by soaking in warm water.

Is it possible to bond Elastic Resin 60A parts together?

Yes, specialized adhesives for elastomers or silicone-based glues can be used to bond parts.

Why are my Elastic Resin 60A prints deforming during printing?

Deformation can occur due to insufficient support or incorrect print settings. Ensure proper support placement and adjust settings as per guidelines.

What causes tearing or ripping in prints?

Thin features or aggressive handling can lead to tearing. Design parts with adequate thickness and handle with care.

How do I prevent bubbles or voids in my prints?

Bubbles can result from trapped air. Allow the resin to settle before printing and pour it slowly to minimize air inclusion.

Why are my prints sticky after curing?

Incomplete curing can leave the surface tacky. Extend curing time and ensure even exposure to UV light.

How do I fix surface imperfections in Elastic Resin 60A prints?

Surface defects can be minimized by adjusting print settings and ensuring the resin and vat are clean.

Can Elastic Resin 60A be used for medical applications?

Unless specifically certified, it is not recommended for medical applications involving prolonged skin contact or implantation.

How does temperature affect Elastic Resin 60A parts?

The resin has low heat resistance and may deform at temperatures above 30°C. It is not suitable for high-temperature applications.

Is Elastic Resin 60A biocompatible or hypoallergenic?

Check with the manufacturer for biocompatibility certifications. Standard resins may not be suitable for sensitive applications without proper testing.

Can I mix Elastic Resin 60A with other resins to adjust hardness?

Mixing resins is not recommended as it can lead to unpredictable results and compromise material properties.

How should I store Elastic Resin 60A to maintain its properties?

Store in its original container, sealed tightly, away from light and heat sources. Avoid exposure to moisture.

Elastic Resin 3D Printing | Flexible Resin 60A in India

Material Name:

Elastic Resin 60A

Description:

Elastic Resin 60A is a specialized flexible resin formulated for elastic resin 3D printing, producing soft parts with rubber-like elasticity. With a Shore hardness of 60A, it is the softest elastomeric resin available for SLA 3D printing, making it suitable for applications requiring high flexibility, compression, and stretchability. This flexible resin enables the creation of parts that can withstand repeated bending and flexing without tearing, such as gaskets, seals, grips, and wearable prototypes. For slightly firmer parts, consider Flexible Resin 80A. Order elastic resin 3D prints in India for your next flexible component.

Material Type:

Elastomeric Photopolymer Resin

Price:

Available color:

Translucent Clear

White

Process compatibility:

SLA compatible

DLP compatible

Special Properties:

Soft and Highly Flexible (Shore 60A)
Rubber-Like Elasticity
Excellent Tear Resistance
Good Compression Properties

Limitations:

UV Sensitivity
Requires Careful Handling
Limited Chemical Resistance
Not Suitable for High-Temperature Applications

Key Elastic Resin properties rated to guide you in selecting the best fit for your 3D printing needs.

Strength2 of 5

Flexibility5 of 5

Detail Resolution4 of 5

Surface Smoothness5 of 5

Heat Resistance1 of 5

Chemical Resistance2 of 5

Ease of Printing3 of 5

Cost Efficiency2 of 5

Elastic Resin 60A is ideal for producing soft, flexible parts that require rubber-like properties. It is suitable for prototyping and testing products that need to withstand bending, stretching, and compression.

Medical and Wearables Applications

Custom-fit wearables

Medical device prototypes
Prosthetics

Consumer Products Applications

Grips and handles

Gaskets and seals
Flexible enclosures

Engineering and Testing Applications

Vibration dampening components

Soft-touch prototypes
Compression springs

Art and Design Applications

Flexible sculptures

Fashion accessories
Interactive models

Additional Applications

Soft Robotics

Ergonomic Prototypes
Functional Elastomeric Parts

Offers high flexibility and elasticity with excellent tear resistance, suitable for parts that require significant stretching and compression without tearing.

Property	Value, metric
Tensile Strength	Approximately 4 MPa
Tensile Modulus	Approximately 7 MPa
Elongation at Break (%)	160%
Flexural Strength	Approximately 4 MPa
Flexural Modulus	Approximately 7 MPa
Notched Izod Impact Strength	Approximately 19 kN/m
Shore Hardness	Shore A 60

Characteristics

Printing with Elastic Resin 60A requires careful handling due to its softness and flexibility. Adjusted support structures and print settings are necessary to accommodate the material's properties. Post-processing includes thorough cleaning and UV curing to achieve optimal elasticity.

Type	Value
Lead Time	2-5 business days
Wall Thickness	Minimum 1.0 mm
Tolerance	±0.2%, minimum ±0.1 mm
Max Part Size	Up to 600x 600 x 450 mm
Layer Height	-

Thermal Properties

Low heat resistance; not suitable for high-temperature environments.

Property	Value, metric
Heat Deflection Temperature (HDT)	Approximately 20°C at 0.455 MPa
Thermal Expansion Coefficient	Approximately 250 x 10^-6 /°C
Thermal Expansion (Scale 0-100)	90
Max Service Temperature	Up to 30°C before significant deformation may occur

Electrical Properties

Acts as an electrical insulator; suitable for non-conductive applications.

Property	Value, metric
ESD Safety	Not ESD safe
Conductivity	Non-conductive; insulating properties

NOTE: The provided values are approximate and can vary based on the specific Elastic Resin formulation and manufacturer. Always refer to the manufacturer's technical data sheet for precise information.

Find your queries

Frequently Asked Question(FAQ)

What is elastic resin 3D printing and when should I use flexible resin?: Elastic resin 3D printing uses flexible resin materials like Elastic Resin 60A to produce soft, rubber-like parts with a Shore hardness of 60A. Use this flexible resin when you need parts that can bend, stretch, and compress—such as wearables, gaskets, and seals.

How does Elastic Resin 60A compare to Flexible Resin 80A?: Elastic Resin 60A is softer and more flexible than Flexible Resin 80A, making it suitable for applications requiring greater elasticity and lower hardness.

Is Elastic Resin 60A suitable for functional prototypes?: Yes, it is ideal for functional prototypes that need to demonstrate flexibility and elasticity, such as wearable devices, seals, and soft-touch components.

Can Elastic Resin 60A be used for end-use parts?: While primarily used for prototyping, it can be used for end-use parts in low-stress applications. Evaluate based on specific requirements and environmental conditions.

Does Elastic Resin 60A require special storage conditions?: Store it in a cool, dark place away from direct sunlight and UV light sources. Keep the container sealed tightly to maintain resin quality.

Are there any special considerations when printing with Elastic Resin 60A?: Yes, due to its softness, it may require adjusted support structures and careful handling to prevent deformation during printing and post-processing.

What layer height is recommended for printing with Elastic Resin 60A?: Layer heights between 50-100 microns are recommended. Smaller layer heights can improve surface finish but may increase print time.

How does Elastic Resin 60A's viscosity affect the printing process?: It may have higher viscosity, which can affect layer adhesion and peel forces. Ensure your printer can handle the resin's properties.

Do I need to adjust exposure settings for Elastic Resin 60A?: Yes, consult the manufacturer's guidelines for optimal exposure settings, as they may differ from standard resins.

Can I print thin features with Elastic Resin 60A?: Features should be designed with a minimum thickness of 1.0 mm to ensure structural integrity and prevent tearing.
