Material Name:

BioMed Resin

Description:

BioMed Resin is formulated to meet biocompatibility standards for medical and dental applications. It is designed for use in devices and components that require prolonged skin or mucosal membrane contact. The resin offers high strength, wear resistance, and can be sterilized using common methods such as autoclaving or gamma radiation.

Material Type:

Biocompatible Photopolymer Resin

Price:

Available color:

Clear

White

Process compatibility:

SLA compatible

DLP compatible

Special Properties:

Biocompatible (ISO 10993 Certified)
Sterilizable
High Dimensional Accuracy
Good Mechanical Strength

Limitations:

Requires Strict Post-Processing Protocols
UV Sensitivity
Limited Color Options
Higher Cost

Key BioMed Resin properties rated to guide you in selecting the best fit for your 3D printing needs.

Strength4 of 5

Flexibility2 of 5

Detail Resolution5 of 5

Surface Smoothness5 of 5

Heat Resistance3 of 5

Chemical Resistance3 of 5

Ease of Printing3 of 5

Cost Efficiency2 of 5

BioMed Resin is ideal for producing medical and dental components that require biocompatibility and sterilization. It enables the creation of patient-specific devices and models with high precision and safety standards.

Medical Devices Applications

Surgical guides

Implantable components (short-term)
Custom orthopedic devices

Dental Applications

Dental models

Orthodontic appliances
Denture bases

Healthcare Applications

Prosthetics

Hearing aids
Diagnostic equipment components

Research and Development Applications

Anatomical models

Medical device prototypes
Tissue engineering scaffolds

Additional Applications

Patient-Specific Implants

Biocompatible Tooling
Custom Medical Solutions

Provides high strength and wear resistance suitable for functional medical and dental components.

Property	Value, metric
Tensile Strength	Approximately 60 MPa
Tensile Modulus	Approximately 2,500 MPa
Elongation at Break (%)	6%
Flexural Strength	Approximately 100 MPa
Flexural Modulus	Approximately 2,500 MPa
Notched Izod Impact Strength	Approximately 25 J/m
Shore Hardness	Shore D 85

Characteristics

Printing with BioMed Resin requires strict adherence to handling and post-processing protocols to maintain biocompatibility. Equipment and workspace cleanliness are critical. Post-processing includes thorough cleaning, UV curing, and sterilization.

Type	Value
Lead Time	2-5 business days
Wall Thickness	Minimum 0.5 mm
Tolerance	±0.05%, minimum ±0.02 mm
Max Part Size	Up to 600x 600 x 450 mm
Layer Height	-

Thermal Properties

Moderate heat resistance; suitable for parts that may undergo sterilization processes.

Property	Value, metric
Heat Deflection Temperature (HDT)	Approximately 70°C at 0.455 MPa
Thermal Expansion Coefficient	Approximately 80 x 10^-6 /°C
Thermal Expansion (Scale 0-100)	65
Max Service Temperature	Up to 65°C before significant deformation may occur

Electrical Properties

Acts as an electrical insulator; suitable for non-conductive applications.

Property	Value, metric
ESD Safety	Not ESD safe
Conductivity	Non-conductive; exhibits insulating properties.

NOTE: The provided values are approximate and can vary based on the specific BioMed Resin formulation and manufacturer. Always refer to the manufacturer's technical data sheet for precise information.

Find your queries

Frequently Asked Question(FAQ)

What is BioMed Resin, and what are its main characteristics?: BioMed Resin is a biocompatible photopolymer resin designed for SLA 3D printing, suitable for medical and dental applications requiring sterilizable, safe-to-use components.

Is BioMed Resin certified for medical use?: Yes, BioMed Resin is typically certified under ISO 10993 for biocompatibility. Always verify the specific certifications and compliance with regulatory requirements in your region.

Can BioMed Resin be sterilized?: Yes, it can be sterilized using common methods such as autoclaving, ethylene oxide, or gamma radiation. Refer to the manufacturer's guidelines for specific sterilization procedures.

Is BioMed Resin suitable for long-term implantation?: BioMed Resin is generally intended for short-term use. For long-term implantation, additional testing and certifications are required. Consult with the manufacturer and regulatory bodies.

What colors are available for BioMed Resin?: It is typically available in clear or white colors, suitable for medical and dental applications.

Are there any special considerations when printing with BioMed Resin?: Yes, strict cleanliness protocols must be followed to maintain biocompatibility. Use dedicated equipment and workspaces to avoid contamination.

What layer height is recommended for printing with BioMed Resin?: Layer heights between 25-50 microns are recommended to achieve high detail resolution and surface finish.

Do I need to adjust exposure settings for BioMed Resin?: Yes, consult the manufacturer's guidelines for optimal exposure settings, as they may differ from standard resins.

Can I use standard SLA printers for BioMed Resin?: Yes, but it's recommended to use printers that are dedicated to medical applications to prevent cross-contamination.

Is an open or closed resin system better for printing with BioMed Resin?: A closed system is preferable to minimize exposure and contamination risks

How should I handle BioMed Resin prints during post-processing?: Use gloves and follow strict hygiene protocols. Post-processing should occur in a clean environment, and parts should be handled minimally to prevent contamination.

How long should I UV cure BioMed Resin prints?: Follow the manufacturer's recommended curing times, typically longer than standard resins, to ensure complete curing and biocompatibility.

How do I sterilize BioMed Resin prints?: Use sterilization methods compatible with the resin, such as autoclaving, ethylene oxide, or gamma radiation. Refer to the manufacturer's guidelines.

Can BioMed Resin prints be painted or colored?: Altering the surface may affect biocompatibility. Any coatings or additives must be biocompatible and approved for medical use.

How do I remove support structures without compromising biocompatibility?: Use sterile tools and handle parts in a clean environment. Supports should be designed to minimize contact with critical areas.

Why are my BioMed Resin prints exhibiting surface defects?: Surface defects can result from contamination, incorrect exposure settings, or equipment issues. Ensure all equipment is clean and properly maintained.

What causes warping or deformation in BioMed Resin prints?: Warping can occur due to internal stresses or inadequate support structures. Ensure proper support placement and adjust print settings as necessary.

How do I prevent contamination of BioMed Resin parts?: Maintain a clean workspace, use dedicated equipment, and follow strict hygiene protocols during printing and post-processing.

Why are my prints not meeting biocompatibility standards?: Ensure that all handling and post-processing procedures align with the manufacturer's guidelines and regulatory requirements.

How do I fix prints adhering too strongly to the build platform?: Adjust initial layer settings or use build platform coatings recommended by the manufacturer.

Can BioMed Resin be mixed with other resins to adjust properties?: No, mixing resins can compromise biocompatibility and is not recommended.

Is BioMed Resin suitable for dental aligners or retainers?: Specific formulations may be suitable for dental applications, but verify with the manufacturer and ensure compliance with dental regulations.

How does humidity affect printing with BioMed Resin?: High humidity can interfere with resin curing and may affect print quality. Print in a controlled environment with low humidity.

Can BioMed Resin be used for tissue engineering or scaffolding?: It may be suitable for certain research applications, but consult with the manufacturer and ensure compliance with relevant regulations.

How should I store BioMed Resin to maintain its properties?: Store in its original, sealed container, away from light, heat sources, and moisture. Follow any specific storage instructions provided by the manufacturer.
