High-quality, accurate 3D printing with our advanced Stereolithography (SLA) technology. Perfect for detailed prototypes and models, we bring your concepts to life with exceptional resolution and surface finish.
Explore our advanced SLA 3D printing capabilities, delivering precision, fine details, and smooth surface finishes across a range of applications. From intricate prototypes to highly detailed models, we ensure high-quality output tailored to your exact specifications.
High Resolution and Detail
Smooth Surface Finish
Rapid Turnaround
| REQUIREMENTS | SPECIFICATIONS |
|---|---|
| Maximum build size | 300 x 300 x 200 mm |
| Standard lead time | 3 business days |
| Dimensional accuracy | ±0.1 mm |
| Layer thickness | 25–100 µm |
| Minimum Feature Size | 0.1mm |
To achieve the best results with SLA 3D printing, it's crucial to follow specific design guidelines that maximize precision, accuracy, and print quality.
Drainage Holes: For hollow parts, include drainage holes of
at least 3 mm diameter to allow uncured resin to
escape.
Orientation Considerations: Part orientation can affect
surface quality and strength; consult with us for optimal
printing orientation.
Avoid Enclosed Volumes: Fully enclosed volumes can trap
uncured resin; design parts to avoid completely enclosed
cavities.
| REQUIREMENTS | SPECIFICATIONS |
|---|---|
| Suggested minimum wall thickness | 600 x 600 x 500mm |
| Supported wall thickness | 4 business days |
| Un-supported wall thickness | 0.5mm |
| Minimum Feature size | 100-300 μm |
| Minimum hole size | 20-100% |
The materials used in SLA 3D printing fall into several categories, each with its own properties, advantages, and limitations. Here's an overview of the main categories of SLA 3D printing materials:
