Tough Resin

Discover Tough Resin—a durable photopolymer resin offering high impact resistance and mechanical strength, ideal for functional prototypes, engineering parts, and applications requiring robustness.

material-imgae-1

Material Name:

Tough Resin

Description:

Tough Resin is a high-strength photopolymer resin designed for SLA 3D printing, formulated to produce parts with enhanced mechanical properties, including high impact resistance and durability. This resin bridges the gap between standard resins and traditional thermoplastics like ABS, making it suitable for functional prototypes, mechanical assemblies, and end-use components. Tough Resin offers excellent dimensional accuracy, smooth surface finishes, and can withstand mechanical stress and strain better than standard resins. It's ideal for engineers and designers seeking to create robust parts that require both precision and strength.

Material Type:

Durable Photopolymer Resin

Price:

indian-rupee-filled indian-rupee-filled indian-rupee indian-rupee indian-rupee

Available color:

Gray
Black
White
Blue

Process compatibility:

  • SLA compatible
    DLP compatible

Special Properties:

  • High Impact Resistance
  • Enhanced Durability
  • Good Mechanical Strength
  • Smooth Surface Finish

Limitations:

  • UV Sensitivity
  • Requires Post-Curing
  • Less Flexible than Some Thermoplastics
  • Moderate Heat Resistance

Material rating

show-details

Key Pro 90% Transparent Resin properties rated to guide you in selecting the best fit for your 3D printing needs.

Strength4 of 5
Flexibility3 of 5
Detail Resolution4 of 5
Surface Smoothness5 of 5
Heat Resistance3 of 5
Chemical Resistance3 of 5
Ease of Printing4 of 5
Cost Efficiency3 of 5

Applications

show-details

Tough Resin is ideal for producing durable prototypes, functional parts, and mechanical assemblies that require high strength and impact resistance. Its mechanical properties make it suitable for testing and end-use applications where standard resins would fail.

Engineering and Manufacturing Applications
  • Functional prototypes
    Snap-fit assemblies
  • Mechanical components
Automotive Applications
  • Interior and exterior parts
    Mounting brackets
  • Custom tools
Consumer Products Applications
  • Wearable device components
    Durable enclosures
  • Sporting goods prototypes
Robotics and Automation Applications
  • Robot parts
    Gears and linkages
  • Custom fixtures
Additional Applications
  • Mechanical Testing Models
    End-Use Parts
  • Durable Prototypes

Mechanical Properties

show-details

Provides high strength, toughness, and impact resistance, suitable for functional parts subjected to stress and strain.

Property Value, metric
Tensile StrengthApproximately 55 MPa
Tensile ModulusApproximately 2,500 MPa
Elongation at Break (%)25%
Flexural StrengthApproximately 90 MPa
Flexural ModulusApproximately 2,300 MPa
Notched Izod Impact StrengthApproximately 65 J/m
Shore HardnessShore D 85

Characteristics

show-details

Printing with Tough Resin follows standard SLA procedures but may require slightly adjusted exposure settings to accommodate its properties. Post-processing includes cleaning and UV curing to achieve maximum mechanical strength and durability.

Type Value
Lead Time2-5 business days
Wall ThicknessMinimum 0.8 mm
Tolerance±0.1%, minimum ±0.05 mm
Max Part SizeUp to 600x 600 x 450 mm
Layer Height-

Thermal Properties

show-details

Offers moderate heat resistance; suitable for parts exposed to elevated temperatures but not high-heat environments.

Property Value, metric
Heat Deflection Temperature (HDT)Approximately 55°C at 0.455 MPa
Thermal Expansion CoefficientApproximately 80 x 10^-6 /°C
Thermal Expansion (Scale 0-100)70
Max Service TemperatureUp to 50°C before significant deformation may occur

Electrical Properties

show-details

Acts as an electrical insulator with moderate dielectric properties; suitable for non-conductive applications.

Property Value, metric
ESD SafetyNot ESD safe
ConductivityNon-conductive; insulating properties
info-iconNOTE: The provided values are approximate and can vary based on the specific Tough Resin formulation and manufacturer. Always refer to the manufacturer's technical data sheet for precise information.

Find your queries

Frequently Asked Question(FAQ)

What is Tough Resin, and what are its main characteristics?
How does Tough Resin compare to standard resin? content-show
Is Tough Resin suitable for mechanical parts and assemblies? content-show
Can Tough Resin be used as a substitute for ABS plastic? content-show
Is Tough Resin safe to handle? content-show
